TECHNICAL DATA:
- transferring: simultaneous double-sided at one time
- 2 heating plates: 310 x 560 mm
- speed for 30 s heating: 1,120 mm/min
- speed for 40 s heating: 840 mm/min
- adjustable temperature: from 1⁰C up to 220⁰ C
- adjustable heating time
- adjustable pneumatic pressure of heating plates
- system of precise image adjustment on two sides
- maximum power consumption: 6.5 kW
- minimum power consumption: 60 W
- power supply: 3 x 400 V, 1 x 230 V
- weight: 388 kg
- dimensions: D=1,360 mm, W=1,560 mm, S=720 mm
- compressed air demand: approx. 1.5 l/cycle, 6 bar
PRODUCTIVITY:
- 500 pcs/1h, double-sided printed lanyards with a width of 15 mm
SECURITIES:
- 2 x E stop mushroom
- automatic shutdown of the machine in case of drive control errors or lack of compressed air
- S-type overcurrent protection
OTHER:
- special equipment (so-called portable table) that allows transferring on tape widths: 5 mm, 10 mm, 15 mm, 20 mm, 25 mm, e.g.: advertising lanyards, clothing labels, elastic suspenders, scarves, shoe laces etc.
- recommended width of sublimation paper - 21 cm
- CE declaration
- DTR
